You can download the 3D model of the bearing by clicking on its.Information regarding the correct use of parametric data in 3D models can be found HERE.
| Lagerbezeichnung | Abmessungen mm |
Tragzahl kN |
Grenzdrehzahl für Schmierung min-1 |
Gewicht kg |
Pict. | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
d | D | T | d1 | d2 | d3 | B | T1 |  C |
 Co |
 |
 |
 |
 |
|
| PLC 06-204 | 45,2 | 94,5 | 50,5 | 95 | 57 | - | 16 | 21 | 20,3 | 16,3 | 5300 | - | 0,780 | 9 | |
| KZI-5 | 68 | 115 | 58 | 102 | 76,4 | - | 55 | 39 | 27,6 | 23,3 | 4200 | - | 1,420 | 10 | |
| KZI/Z-5/T | 68 | 128 | 51 | 106 | 90 | 100 | 42,5 | 33,5 | 33,5 | 27,6 | 4000 | - | 1,880 | 11 | |
| PLC 08-13 | 106 | 145 | - | 138 | - | - | 18 | 25 | 23,8 | 24,3 | 2500 | - | 0,940 | 12 | |
